Old May 10, 2004 | 04:38 PM
Share
  #16
IS2Scooby's Avatar
IS2Scooby
Thread Starter
Pr0n King
iTrader: (3)

Joined: Nov 2002
Posts: 26,618
From: The Land of Rocks
Car Info: Turncoat Turbo
I've pulled MORE than 2 degrees across the board (as many as 4 degrees in some places from the BASE map!) and it still knocks on 92. I've added a bit of fuel to the knock prone areas - but I'd much rather mess with timing than fuel (I think we're alike in that respect).

Maybe I'll have to get rid of the MBC, go to the UTEC boost control and regulate the onset of boost. That's the only factor that I'm not controlling very tightly.

I'm trying to save money, and fortifying my tank with $6.009/gallon 100 octane from 76 ain't helpin'.
__________________
Best Car Insurance | Auto Protection Today | FREE Trade-In Quote
Reply
Old May 10, 2004 | 05:48 PM
Share
  #17
Darknight's Avatar
Darknight
Registered User

Joined: Oct 2003
Posts: 135
From: 808
Car Info: 2002 Black WRX
How does your current map look like? Are you running the currrent 4.2 firmware?
Reply
Old May 10, 2004 | 08:47 PM
Share
  #18
IS2Scooby's Avatar
IS2Scooby
Thread Starter
Pr0n King
iTrader: (3)

Joined: Nov 2002
Posts: 26,618
From: The Land of Rocks
Car Info: Turncoat Turbo
I haven't upgraded the firmware in a while.

Folks, what I'm looking for here is examples of your ignition tables on stage 4 cars. I'll go get mine and post it and you guys can compare.
__________________
Best Car Insurance | Auto Protection Today | FREE Trade-In Quote
Reply
Old May 11, 2004 | 01:14 AM
Share
  #19
oldmansan's Avatar
oldmansan
Registered User
iTrader: (4)

Joined: Dec 2002
Posts: 2,176
From: Southern California
Car Info: 2016 Z51 C7, 2007 Exige S, 2008 ZX-10R, 2016 Taco
Here's what I'm running (FMIC)
Timing Map
[-100] [-100] [-100] [-100] [-100] [-100] [-100] [-100] [-100] [-100] [-100]

[-100] [-100] [-100] [-100] [-100] [-100] [-100] [-100] [-100] [-100] [-100]

[-100] [-100] [-100] [-100] [-100] [30] [30] [30] [30] [30] [30]

[-100] [-100] [-100] [-100] [-100] [30] [30] [30] [30] [30] [30]

[-100] [-100] [-100] [-100] [-100] [30] [30] [30] [30] [30] [30]

[-100] [-100] [-100] [-100] [-100] [30] [30] [30] [30] [30] [30]

[-100] [-100] [-100] [-100] [-100] [30] [30] [30] [30] [30] [30]

[-100] [-100] [-100] [-100] [-100] [30] [30] [30] [30] [30] [30]

[-100] [-100] [-100] [-100] [-100] [30] [30] [30] [30] [30] [30]

[-100] [-100] [-100] [-100] [-100] [30] [30] [30] [30] [30] [28]

[-100] [-100] [-100] [-100] [-100] [27] [27] [27] [27] [27] [26]

[-100] [-100] [-100] [-100] [-100] [24] [24] [24] [24] [22] [22]

[-100] [-100] [-100] [-100] [-100] [23] [23] [22] [21] [20] [20]

[-100] [-100] [-100] [-100] [-100] [20] [19] [17] [17] [16] [15]

[-100] [-100] [-100] [-100] [-100] [20] [19] [17] [16] [16] [15]

[-100] [-100] [-100] [-100] [-100] [20] [19] [17] [15] [15] [15]

[-100] [-100] [-100] [-100] [-100] [20] [19] [17] [15] [14] [13]

[-100] [-100] [-100] [-100] [-100] [19] [17] [16] [16] [13] [12]

[-100] [-100] [-100] [-100] [-100] [19] [17] [16] [15] [13] [12]

[-100] [-100] [-100] [-100] [-100] [21] [20] [18] [17] [15] [13]

[-100] [-100] [-100] [-100] [-100] [24] [23] [20] [19] [17] [16]

[-100] [-100] [-100] [-100] [-100] [24] [23] [21] [20] [19] [18]

[-100] [-100] [-100] [-100] [-100] [24] [23] [21] [20] [20] [19]

[-100] [-100] [-100] [-100] [-100] [24] [23] [21] [20] [20] [19]

[-100] [-100] [-100] [-100] [-100] [24] [23] [21] [20] [20] [19]

[-100] [-100] [-100] [-100] [-100] [24] [23] [22] [21] [21] [20]

[-100] [-100] [-100] [-100] [-100] [25] [24] [23] [23] [22] [21]

[-100] [-100] [-100] [-100] [-100] [25] [24] [23] [23] [22] [21]

[-100] [-100] [-100] [-100] [-100] [25] [24] [23] [23] [22] [21]

[-100] [-100] [-100] [-100] [-100] [22] [22] [22] [22] [22] [22]

[-100] [-100] [-100] [-100] [-100] [22] [22] [22] [22] [22] [22]

[-100] [-100] [-100] [-100] [-100] [22] [22] [22] [22] [22] [22]

[-100] [-100] [-100] [-100] [-100] [22] [22] [22] [22] [22] [22]

[-100] [-100] [-100] [-100] [-100] [22] [22] [22] [22] [22] [22]

[-100] [-100] [-100] [-100] [-100] [22] [22] [22] [22] [22] [22]

[-100] [-100] [-100] [-100] [-100] [22] [22] [22] [22] [22] [22]

[-100] [-100] [-100] [-100] [-100] [22] [22] [22] [22] [22] [22]

[-100] [-100] [-100] [-100] [-100] [-100] [-100] [-100] [-100] [-100] [-100]

[-100] [-100] [-100] [-100] [-100] [-100] [-100] [-100] [-100] [-100] [-100]

[-100] [-100] [-100] [-100] [-100] [-100] [-100] [-100] [-100] [-100] [-100]

This is a 20psi 91 octane Stage 4 VF30 FMIC map. I need to do some more logging, but even at high boost levels (20+) I've seen no knock. Wondering how it would fare with a TMIC.

San
Reply
Old May 11, 2004 | 04:28 AM
Share
  #20
IS2Scooby's Avatar
IS2Scooby
Thread Starter
Pr0n King
iTrader: (3)

Joined: Nov 2002
Posts: 26,618
From: The Land of Rocks
Car Info: Turncoat Turbo
Thanks, San. Exactly what I'm looking for. Wow, that timing is pretty darned low. I guess I'll have to rethink my strategy on ignition advance on 92 octane swill.
__________________
Best Car Insurance | Auto Protection Today | FREE Trade-In Quote
Reply
Old May 11, 2004 | 02:17 PM
Share
  #21
gpatmac's Avatar
gpatmac
VIP Member
iTrader: (3)

Joined: Nov 2002
Posts: 10,133
From: Lastweek Lane - Watertown, NY
Car Info: 02WRXpseudoSTiWannabeWagon
Code:
Timing Map
   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]
   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]
   [-100]     [30]     [30]     [30]     [30]     [30]     [31]     [31]     [31]     [32]     [32]
   [-100]     [30]     [30]     [30]     [30]     [30]     [31]     [31]     [31]     [32]     [32]
   [-100]     [28]     [28]     [28]     [28]     [28]     [29]     [29]     [29]     [30]     [30]
   [-100]     [28]     [28]     [28]     [28]     [28]     [29]     [29]     [29]     [30]     [30]
   [-100]     [28]     [28]     [28]     [28]     [28]     [29]     [29]     [29]     [30]     [30]
   [-100]     [28]     [28]     [28]     [28]     [28]     [29]     [29]     [29]     [30]     [30]
   [-100]     [28]     [28]     [28]     [28]     [28]     [29]     [29]     [29]     [30]     [30]
   [-100]     [28]     [28]     [28]     [28]     [28]     [29]     [29]     [29]     [30]     [30]
   [-100]     [28]     [28]     [28]     [28]     [28]     [29]     [29]     [29]     [30]     [30]
   [-100]     [28]     [28]     [28]     [28]     [28]     [29]     [29]     [29]     [30]     [30]
   [-100]     [28]     [28]     [28]     [28]     [28]     [29]     [29]     [29]     [30]     [30]
   [-100]     [18]     [18]     [18]     [18]     [18]     [19]     [19]     [19]     [20]     [20]
   [-100]     [15]     [15]     [15]     [15]     [15]     [16]     [16]     [16]     [17]     [17]
   [-100]     [14]     [14]     [14]     [14]     [14]     [15]     [15]     [15]     [16]     [16]
   [-100]     [14]     [14]     [14]     [14]     [14]     [15]     [15]     [15]     [16]     [16]
   [-100]     [15]     [15]     [15]     [15]     [15]     [16]     [16]     [16]     [17]     [17]
   [-100]     [16]     [16]     [16]     [16]     [16]     [17]     [17]     [17]     [18]     [18]
   [-100]     [17]     [17]     [17]     [17]     [17]     [18]     [18]     [18]     [19]     [19]
     [20]     [18]     [18]     [18]     [18]     [18]     [19]     [19]     [20]     [20]     [20]
     [20]     [19]     [19]     [19]     [19]     [19]     [20]     [20]     [21]     [21]     [21]
     [20]     [19]     [19]     [19]     [19]     [19]     [20]     [20]     [21]     [21]     [21]
     [20]     [20]     [20]     [20]     [20]     [20]     [21]     [21]     [22]     [22]     [22]
     [20]     [20]     [20]     [20]     [20]     [20]     [21]     [21]     [22]     [22]     [22]
     [20]     [21]     [21]     [21]     [21]     [21]     [22]     [22]     [23]     [23]     [23]
     [20]     [22]     [22]     [22]     [22]     [22]     [23]     [23]     [24]     [24]     [24]
     [20]     [23]     [23]     [23]     [23]     [23]     [24]     [24]     [25]     [25]     [25]
     [20]     [24]     [24]     [24]     [24]     [24]     [25]     [25]     [26]     [26]     [26]
     [20]     [24]     [24]     [24]     [24]     [24]     [25]     [25]     [26]     [26]     [26]
     [20]     [24]     [24]     [24]     [24]     [24]     [25]     [25]     [26]     [26]     [26]
     [20]     [24]     [24]     [24]     [24]     [24]     [25]     [25]     [26]     [26]     [26]
     [20]     [24]     [24]     [24]     [24]     [24]     [25]     [25]     [26]     [26]     [26]
     [20]     [24]     [24]     [24]     [24]     [24]     [25]     [25]     [26]     [26]     [26]
     [20]     [24]     [24]     [24]     [24]     [24]     [25]     [25]     [26]     [26]     [26]
     [20]     [24]     [24]     [24]     [24]     [24]     [25]     [25]     [26]     [26]     [26]
     [20]     [24]     [24]     [24]     [24]     [24]     [25]     [25]     [26]     [26]     [26]
   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]
   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]
   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]   [-100]
Hey, where's the toolbox?
Reply
Old May 12, 2004 | 07:55 PM
Share
  #22
oldmansan's Avatar
oldmansan
Registered User
iTrader: (4)

Joined: Dec 2002
Posts: 2,176
From: Southern California
Car Info: 2016 Z51 C7, 2007 Exige S, 2008 ZX-10R, 2016 Taco
Not sure
what you mean by "low". I had to remind someone at the track that was knocking badly that lower numbers are more prone to knock than higher numbers as the numbers represent actual degrees before TDC. He was "lowering" his numbers and wondering why he was knocking. I haven't even played with this map to see if I can tune some more power out of it.

San
Reply
Old May 12, 2004 | 08:21 PM
Share
  #23
IS2Scooby's Avatar
IS2Scooby
Thread Starter
Pr0n King
iTrader: (3)

Joined: Nov 2002
Posts: 26,618
From: The Land of Rocks
Car Info: Turncoat Turbo
Originally Posted by oldmansan
what you mean by "low". I had to remind someone at the track that was knocking badly that lower numbers are more prone to knock than higher numbers as the numbers represent actual degrees before TDC. He was "lowering" his numbers and wondering why he was knocking. I haven't even played with this map to see if I can tune some more power out of it.

San
San, I think you need to rethink that one...

You're setting total timing, not retarding timing from a set total. The UTEC has complete control of timing.

Lower #'s = lower total timing.

Higher #'s = higher timing (most likely more knock).
__________________
Best Car Insurance | Auto Protection Today | FREE Trade-In Quote
Reply
Old May 12, 2004 | 08:45 PM
Share
  #24
oldmansan's Avatar
oldmansan
Registered User
iTrader: (4)

Joined: Dec 2002
Posts: 2,176
From: Southern California
Car Info: 2016 Z51 C7, 2007 Exige S, 2008 ZX-10R, 2016 Taco
I'm quoting from the manual,
under
"IGNITION TUNING

7. The values that are typed in each RPM/Load point in the timing map are actual ignition timing in dergrees "Before Top Dead Center" (BTDC)."

That's what my manual says. Am I missing something? If so let me know.

San
Reply
Old May 12, 2004 | 08:57 PM
Share
  #25
IS2Scooby's Avatar
IS2Scooby
Thread Starter
Pr0n King
iTrader: (3)

Joined: Nov 2002
Posts: 26,618
From: The Land of Rocks
Car Info: Turncoat Turbo
The words you should be focusing on are "actual ignition timing". All timing stats are given in BTDC (you wouldn't want the spark to fire AFTER the piston is at the top of it's travel, right?)

Trust me on this one.

i.e. When the manual on an old V8 said "set initial timing to 10 degrees" (the implied portion was BTDC). When you set an engine to have "total timing of 32 degrees" it's in BTDC as well.

You're ADVANCING the spark event, meaning you do it EARLIER in crank rotation in degrees. This gives you a higher total timing number.

Retarding the timing means you do it LATER in the crank rotation cycle which puts the spark event closer to the piston being at the top of it's travel. That gives you a lower total timing number.
__________________
Best Car Insurance | Auto Protection Today | FREE Trade-In Quote
Last edited by IS2Scooby; May 12, 2004 at 08:59 PM.
Reply
Old May 12, 2004 | 09:43 PM
Share
  #26
oldmansan's Avatar
oldmansan
Registered User
iTrader: (4)

Joined: Dec 2002
Posts: 2,176
From: Southern California
Car Info: 2016 Z51 C7, 2007 Exige S, 2008 ZX-10R, 2016 Taco
Ok
Let me try this out. So if I increase the number of degrees BTDC I have an increased chance of knock because the the explosion will "fight" the rotating assembly? And by running a lower number (closer to BTDC) it's "safer" because it's closer to BTDC and less likely to knock? If so that's great because I probably have a lot more power to tune for. As long as I don't see knock I should be increasing my numbers?

San
Reply
Old May 12, 2004 | 11:29 PM
Share
  #27
oldmansan's Avatar
oldmansan
Registered User
iTrader: (4)

Joined: Dec 2002
Posts: 2,176
From: Southern California
Car Info: 2016 Z51 C7, 2007 Exige S, 2008 ZX-10R, 2016 Taco
Well,
I've done some reading, and it appears I am like my timing, "retarded".

San
Reply
Old May 12, 2004 | 11:46 PM
Share
  #28
Mach5WRX's Avatar
Mach5WRX
Angry Dan
iTrader: (9)

Joined: Nov 2002
Posts: 7,183
From: www.turboculture.com
Car Info: 05 Evo VIII
Don't worry San...... here is some funnAy for you..... www.foctor.com/funnypics/products/fosters.jpg

***WARNING***
Last edited by Mach5WRX; May 12, 2004 at 11:55 PM.
Reply
Old May 12, 2004 | 11:49 PM
Share
  #29
Mach5WRX's Avatar
Mach5WRX
Angry Dan
iTrader: (9)

Joined: Nov 2002
Posts: 7,183
From: www.turboculture.com
Car Info: 05 Evo VIII
Attached Thumbnails Hawaii Stage 4 UTEC Users-fosters.jpg
Reply
Old May 12, 2004 | 11:50 PM
Share
  #30
Mach5WRX's Avatar
Mach5WRX
Angry Dan
iTrader: (9)

Joined: Nov 2002
Posts: 7,183
From: www.turboculture.com
Car Info: 05 Evo VIII
Dude is looking right at her a$$...
Attached Thumbnails Hawaii Stage 4 UTEC Users-fosters%2520pinup.jpg
Reply



Advanced Search

All times are GMT -7. The time now is 11:13 AM.
