Springs?
#4
Registered User
iTrader: (2)
Join Date: Dec 2003
Location: Danville, CA
Posts: 258
Car Info: Audi Q5 aka "the old man wagon"
I have megan racing coils on my car, but on previous cars I've had springs from H&R, neuspeed, vogtland, and eibach.
H&R were pretty good, decent drop, and a pretty stiff ride.
not the best of the lot, but vogtland doesnt make springs for subarus so of they ones out there I'd go with H&R.
H&R were pretty good, decent drop, and a pretty stiff ride.
not the best of the lot, but vogtland doesnt make springs for subarus so of they ones out there I'd go with H&R.
Last edited by 1SIKBRU; 12-12-2008 at 11:43 AM.
#9
Registered User
iTrader: (2)
Join Date: Dec 2003
Location: Danville, CA
Posts: 258
Car Info: Audi Q5 aka "the old man wagon"
the coilovers are stiffer than any set of springs you can buy. They are borderline uncomfortable, but they are fun.
If you are unsure then just go with the springs, and possibly sway bars. I have the rear sway and that made a huge difference, need to get the front one soon too.
If you are unsure then just go with the springs, and possibly sway bars. I have the rear sway and that made a huge difference, need to get the front one soon too.
#10
VIP Member
iTrader: (22)
Join Date: Jul 2006
Location: Vacaville
Posts: 9,542
Car Info: 2017 CWP WRX & 2007 SWP WRX
I have Cobb Sport Springs on my car for a 25mm drop front and rear with spring rates increased by 10% in the front and 20% in the rear.
Here's the 08 STi spring review I did on IWSTI, but it's for 08 STis and their will be a difference when comparing the companies WRX and STi spring facts (spring rate and drop) because of the difference in WRX and STi stock set ups.
But it should give you a good idea as too some companies to look into.
Good luck, and I insist going some what conservative with your drop. Too much may lead to lots of negative camber, increased tire wear, a harsh ride, and eventually strut issues (which the WRX may be more inclined to than the STi because of the difference in the strength of the factory struts).
-Steven
Here's the 08 STi spring review I did on IWSTI, but it's for 08 STis and their will be a difference when comparing the companies WRX and STi spring facts (spring rate and drop) because of the difference in WRX and STi stock set ups.
But it should give you a good idea as too some companies to look into.
Good luck, and I insist going some what conservative with your drop. Too much may lead to lots of negative camber, increased tire wear, a harsh ride, and eventually strut issues (which the WRX may be more inclined to than the STi because of the difference in the strength of the factory struts).
-Steven
Contents
A. Factory 2008 STi Spring Facts
B. After Market Springs
1. Agency Power Performance Springs
2. Cobb Tuning Sport Springs
3. Eibach Pro-Kit Springs
4. RaceComp Engineering Functional Lowering Springs
5. RaceComp Engineering Sport Lowering Springs
6. Subaru JDM Pink STi Springs
7. Swift Sport Springs
8. Tanabe DF210 Springs
9. Tein S-Tech Springs
C. Springs Listed from Most Lowered to Least Lowered
D. Springs Listed from Highest to Lowest Spring Rates
------------------------------------------------------------------------------------
A. Factory 2008 STi Spring Facts
Link:
Front Spring Rate: No Info Found
Rear Spring Rate: No Info Found
------------------------------------------------------------------------------------
B. After Market Spring Facts
1. Agency Power Performance Racing Springs
Link: Agency Power Performance Racing Springs Subaru WRX STI 08+
Front Drop: 1 1/4” (32mm)
Front Spring Rate & Increase: No Info Found
Rear Drop: 3/4” (19mm)
Rear Spring Rate &Increase: No Info Found
Skid Pad: No Info Found
Cost: $250 @ Agency-Power.com
2. Cobb Tuning Sport Springs
Link: CobbTuning.com - 08 STI Sport Springs
Front Drop: 7/8” (22mm)
Front Spring Rate & Increase: Unknown Rate & 10%
Rear Drop: 7/8” (22mm)
Rear Spring Rate & Increase: Unknown Rate & 20%
Skid Pad: from 0.94 g stock to 1.02 g
Cost: $250 at RallySportDirect.com
3. Eibach Pro-Kit Springs
Link: Eibach Springs - Performance Suspension, Lowering Springs, Shocks, Sway Bars, Coil-Overs and Wheel Spacers!
Front Drop: 1” (25mm)
Front Spring Rate & Increase: No Info Found
Rear Drop: 1” (25mm)
Rear Spring Rate &Increase: No Info Found
Skid Pad: No Info Found
Cost: $270 at Vivid Racing
4. RaceComp Engineering Functional Lowering Springs *Still in Development*
Link: http://www.iwsti.com/forums/1867071-post25.html
Front Drop: 1/5”- 2/5" (5-10mm)
Front Spring Rate & Increase: No Info Found
Rear Drop: 1/5”- 2/5" (5-10mm)
Rear Spring Rate & Increase: No Info Found
Skid Pad: No Info Found
Cost: No Info Found
5. RaceComp Engineering Sport Lowering Springs *Still in Development*
Link: http://www.iwsti.com/forums/1867071-post25.html
Front Drop: 4/5” (20mm)
Front Spring Rate & Increase: No Info Found
Rear Drop: 4/5” (20mm)
Rear Spring Rate & Increase: No Info Found
Skid Pad: No Info Found
Cost: No Info Found
6. Subaru JDM Pink STi Springs
Link: japanparts.com : PARTS DATABASE
Front Drop: 3/5” (15mm)
Front Spring Rate & Increase: 285lb/in & No % Info Found
Rear Drop: 3/5” (15mm)
Rear Spring Rate & Increase: 228lb/in & No % Info Found
Skid Pad: No Info Found
Cost: $480 @ JapanParts.com
7. Swift Sport Springs
Link 1: Mann Engineering - Subaru Parts and Performance
Link 2: NASIOC - View Single Post - Coming Soon! Swift Sport Springs for 2008 STI
Front Drop: 1” (25mm)
Front Spring Rate & Increase: 143-251 lb/in & 10-15%
Rear Drop: 1” (25mm)
Rear Spring Rate &Increase: 118-235 lb/in & 10-15%
Skid Pad: No Info Found
Cost: $310 @ MannEngineering.com
8. Tanabe DF210 Springs
Link: RallySportDirect.com - Tanabe DF210 2008 Sti Springs
Front Drop: 1.1” (28mm)
Front Spring Rate & Increase: 246lb/in & No % Info Found
Rear Drop: 1.1” (28mm)
Rear Spring Rate &Increase: 174lb/in & No % Info Found
Skid Pad: No Info Found
Cost: $275 at RallySportDirect.com
9. Tein S-Tech Springs
Link: S.TECH
Front Drop: 1” (25mm)
Front Spring Rate & Increase: 252 lb/in & No % Info Found
Rear Drop: 8/10” (20mm)
Rear Spring Rate Increase: 219 lb/in & No % Info Found
Skid Pad: No Info Found
Cost: $250 at RallySportDirect.com
------------------------------------------------------------------------------------
C. Springs Listed from Most Lowered to Least Lowered
1. New Agency Power Performance Springs (32/19mm)
2. Tanabe DF210 Springs (28/28mm)
3. Eibach Pro-Kit Springs (25/25mm)
4. Swift Sport Springs (25/25mm)
5. Tein S-Tech Springs (25/20mm)
6. Cobb Tuning Sport Springs (22/22mm)
7. RaceComp Engineering Sport Lower Springs (20/20mm)
8. Subaru JDM Pink STi Springs (15/15mm)
9. RaceComp Engineering Functional Lowering Springs (5-10/5-10mm)
------------------------------------------------------------------------------------
D. Springs Listed from Highest to Lowest Spring Rates
Insufficient data at this time.
------------------------------------------------------------------------------------
I will do my best to update this thread with new information and springs when it becomes available or is brought to my attention
-Steven
A. Factory 2008 STi Spring Facts
B. After Market Springs
1. Agency Power Performance Springs
2. Cobb Tuning Sport Springs
3. Eibach Pro-Kit Springs
4. RaceComp Engineering Functional Lowering Springs
5. RaceComp Engineering Sport Lowering Springs
6. Subaru JDM Pink STi Springs
7. Swift Sport Springs
8. Tanabe DF210 Springs
9. Tein S-Tech Springs
C. Springs Listed from Most Lowered to Least Lowered
D. Springs Listed from Highest to Lowest Spring Rates
------------------------------------------------------------------------------------
A. Factory 2008 STi Spring Facts
Link:
Front Spring Rate: No Info Found
Rear Spring Rate: No Info Found
------------------------------------------------------------------------------------
B. After Market Spring Facts
1. Agency Power Performance Racing Springs
Link: Agency Power Performance Racing Springs Subaru WRX STI 08+
Front Drop: 1 1/4” (32mm)
Front Spring Rate & Increase: No Info Found
Rear Drop: 3/4” (19mm)
Rear Spring Rate &Increase: No Info Found
Skid Pad: No Info Found
Cost: $250 @ Agency-Power.com
2. Cobb Tuning Sport Springs
Link: CobbTuning.com - 08 STI Sport Springs
Front Drop: 7/8” (22mm)
Front Spring Rate & Increase: Unknown Rate & 10%
Rear Drop: 7/8” (22mm)
Rear Spring Rate & Increase: Unknown Rate & 20%
Skid Pad: from 0.94 g stock to 1.02 g
Cost: $250 at RallySportDirect.com
3. Eibach Pro-Kit Springs
Link: Eibach Springs - Performance Suspension, Lowering Springs, Shocks, Sway Bars, Coil-Overs and Wheel Spacers!
Front Drop: 1” (25mm)
Front Spring Rate & Increase: No Info Found
Rear Drop: 1” (25mm)
Rear Spring Rate &Increase: No Info Found
Skid Pad: No Info Found
Cost: $270 at Vivid Racing
4. RaceComp Engineering Functional Lowering Springs *Still in Development*
Link: http://www.iwsti.com/forums/1867071-post25.html
Front Drop: 1/5”- 2/5" (5-10mm)
Front Spring Rate & Increase: No Info Found
Rear Drop: 1/5”- 2/5" (5-10mm)
Rear Spring Rate & Increase: No Info Found
Skid Pad: No Info Found
Cost: No Info Found
5. RaceComp Engineering Sport Lowering Springs *Still in Development*
Link: http://www.iwsti.com/forums/1867071-post25.html
Front Drop: 4/5” (20mm)
Front Spring Rate & Increase: No Info Found
Rear Drop: 4/5” (20mm)
Rear Spring Rate & Increase: No Info Found
Skid Pad: No Info Found
Cost: No Info Found
6. Subaru JDM Pink STi Springs
Link: japanparts.com : PARTS DATABASE
Front Drop: 3/5” (15mm)
Front Spring Rate & Increase: 285lb/in & No % Info Found
Rear Drop: 3/5” (15mm)
Rear Spring Rate & Increase: 228lb/in & No % Info Found
Skid Pad: No Info Found
Cost: $480 @ JapanParts.com
7. Swift Sport Springs
Link 1: Mann Engineering - Subaru Parts and Performance
Link 2: NASIOC - View Single Post - Coming Soon! Swift Sport Springs for 2008 STI
Front Drop: 1” (25mm)
Front Spring Rate & Increase: 143-251 lb/in & 10-15%
Rear Drop: 1” (25mm)
Rear Spring Rate &Increase: 118-235 lb/in & 10-15%
Skid Pad: No Info Found
Cost: $310 @ MannEngineering.com
8. Tanabe DF210 Springs
Link: RallySportDirect.com - Tanabe DF210 2008 Sti Springs
Front Drop: 1.1” (28mm)
Front Spring Rate & Increase: 246lb/in & No % Info Found
Rear Drop: 1.1” (28mm)
Rear Spring Rate &Increase: 174lb/in & No % Info Found
Skid Pad: No Info Found
Cost: $275 at RallySportDirect.com
9. Tein S-Tech Springs
Link: S.TECH
Front Drop: 1” (25mm)
Front Spring Rate & Increase: 252 lb/in & No % Info Found
Rear Drop: 8/10” (20mm)
Rear Spring Rate Increase: 219 lb/in & No % Info Found
Skid Pad: No Info Found
Cost: $250 at RallySportDirect.com
------------------------------------------------------------------------------------
C. Springs Listed from Most Lowered to Least Lowered
1. New Agency Power Performance Springs (32/19mm)
2. Tanabe DF210 Springs (28/28mm)
3. Eibach Pro-Kit Springs (25/25mm)
4. Swift Sport Springs (25/25mm)
5. Tein S-Tech Springs (25/20mm)
6. Cobb Tuning Sport Springs (22/22mm)
7. RaceComp Engineering Sport Lower Springs (20/20mm)
8. Subaru JDM Pink STi Springs (15/15mm)
9. RaceComp Engineering Functional Lowering Springs (5-10/5-10mm)
------------------------------------------------------------------------------------
D. Springs Listed from Highest to Lowest Spring Rates
Insufficient data at this time.
------------------------------------------------------------------------------------
I will do my best to update this thread with new information and springs when it becomes available or is brought to my attention
-Steven
